Injection Molding Cost Breakdown — Tooling, Material, and Per-Part Economics

A buyer sends a 3D file to three molders and receives three quotes. The first quotes $3,800 for the mold and $0.85 per part. The second quotes $8,500 for the mold and $0.52 per part. The third quotes $22,000 for the mold and $0.28 per part.

Which one is right?

All three. They are quoting three different tools: an aluminum prototype mold, a P20 single-cavity production tool, and an H13 four-cavity hot-runner tool. Each is the correct choice — for a different production scenario.

The buyer who does not understand what drives these numbers will choose the lowest mold cost and wonder why the per-part price is high. Or choose the lowest part price and wonder why the tooling investment takes three years to pay back. Understanding the cost structure of injection molding is not about negotiating harder. It is about matching the tooling to the production volume so you are not overpaying for capacity you do not need — or underinvesting in a tool that limits your margin for the next five years.

The Three Components of Injection Molding Cost

Every injection molding quote is built from three components:

The tooling is a fixed cost. The material and processing are variable costs. The total cost of the program is:

Total = Tooling + (Part Cost × Quantity)

At 1,000 parts, the tooling dominates the total. At 1,000,000 parts, the part cost dominates. The economic question is where these two lines cross — and whether the production volume justifies the tooling investment.

What Drives Mold Cost

A mold costs what it costs because of what goes into it. There is no single “mold price.” The price is a function of seven variables.

1. Cavity Count

This is the single largest cost driver. A one-cavity mold produces one part per cycle. A four-cavity mold produces four parts per cycle. The four-cavity mold costs roughly 2.5–3× the one-cavity mold — not 4×, because the mold base, cooling system, and ejector system are shared. But the per-part cost drops proportionally: four parts per cycle means roughly one-quarter the processing cost per part.

2. Steel Grade

Steel cost is not just about the material price per kilogram — which is modest. It is about machinability. P20 machines efficiently with standard carbide tooling. H13, hardened to 50 HRC, requires hard milling with micro-grain carbide at lower feed rates — more machine time, more tool wear, higher cost. S136 demands the same hard milling plus the material premium for stainless.

3. Part Complexity

A simple flat cover with no undercuts, uniform 3mm wall thickness, and a single gate can be machined almost entirely by CNC. A complex housing with 15 ribs, 8 bosses, multiple undercuts requiring side actions, and a textured cosmetic surface requires CNC + sinker EDM + wire EDM + polishing — each operation adding cost.

Complexity drivers ranked by cost impact:

• Side actions (slides) — $800–$2,500 per slide. Each undercut requiring a side action is a separate mechanism that must be designed, machined, fitted, and maintained.
• Lifters — $500–$1,500 per lifter. Internal undercuts that must release during ejection.
• Deep ribs — require EDM electrodes. Each electrode must be designed, machined, and consumed during EDM.
• High polish (SPI A-1/A-2) — 8–20 hours of skilled manual polishing. Cannot be automated.
• Fine texture (VDI < 18) — requires chemical etching with photoresist, tight process control.
• Tight tolerances (±0.02mm or less) — requires hard milling finish pass, additional inspection, potential fitting and rework.

4. Hot Runner vs Cold Runner

A cold runner mold produces a sprue and runner with every shot — plastic that solidifies in the feed channels and is either reground or discarded. A hot runner mold keeps the plastic molten in the manifold, eliminating runner waste.

Hot runners pay back through material savings and cycle time reduction. The payback calculation depends on part weight, runner weight, material cost per kilogram, and annual volume. For a 5-gram part running 500,000 shots per year, eliminating a 3-gram cold runner saves 1,500 kg of material annually — roughly $4,500–$9,000 in engineering resin. The hot runner system pays for itself within 12–18 months.

5. Mold Size

Larger parts require larger mold bases, larger press platens, and more steel removal during machining. A mold for a smartphone housing (150 × 80 × 10mm) uses a mold base approximately 300 × 300mm. A mold for an automotive interior trim panel (800 × 400 × 5mm) uses a mold base approximately 1,000 × 600mm — roughly 6× the steel volume. Machining time, material cost, and handling all scale with mold size.

These five factors interact. A four-cavity H13 mold with a hot runner, two side actions per cavity, and SPI A-2 polish on a part with 150 dimensions and a ±0.05mm tolerance is the top of the cost range. A single-cavity P20 mold with an edge gate, no side actions, and SPI B-2 finish on a simple part is the bottom. Most production molds fall somewhere in between.

What Drives Per-Part Cost

Once the mold is built, every part you order costs:

Part Cost = Material + Machine Time + Labour + Secondary Operations + Packaging

Material

The resin cost is the largest variable component — typically 40–60% of the part cost.

Material cost per part = (Part weight in grams ÷ 1,000) × Resin cost per kg × (1 + scrap rate)

For a 50-gram part in ABS at $4.00/kg with a 3% scrap rate (runner regrind): cost per part = (50 ÷ 1,000) × $4.00 × 1.03 = $0.21.

Machine Time

The injection press costs money every second it runs — electricity, operator labour, overhead allocation, depreciation, and profit margin. The cost is expressed as a machine hour rate (MHR), which for a mid-sized press (160–250 tonnes) in a Shenzhen facility typically ranges from $18–$35 per hour depending on the specific press, automation level, and production complexity.

Processing cost per part = Machine hour rate ÷ (3,600 ÷ cycle time in seconds ÷ number of cavities)

For a 4-cavity mold running a 25-second cycle on a press at $28/hour: cost per part = $28 ÷ (3,600 ÷ 25 ÷ 4) = $28 ÷ 36 = $0.78.

Note: All monetary figures are illustrative. Actual costs depend on resin market pricing, specific part geometry, current press loading, and exchange rates. Every RFQ receives a specific quote based on the actual part file, material specification, and production volume.

The Cavitation Effect

The single largest lever on per-part cost is cavity count. Doubling the cavities roughly halves the processing cost per part:

The material cost does not change with cavitation. For the 50-gram ABS part above, the total per-part cost at 4 cavities is approximately $0.21 (material) + $0.049 (processing) = $0.26.

Secondary Operations

Secondary operations add cost per part but can reduce mold cost — for example, heat-staking a threaded insert after molding avoids an insert-molding side action, which saves $1,500–$2,500 on the tool.

Real Cost Examples

Three representative parts, to give a sense of how the variables combine.

Part A: Small Electronics Clip

• Material: POM, 3 grams, single cavity
• Simple geometry, no side actions, no texture
• P20 mold: $3,500
• Material cost: $0.025 per part
• Cycle time: 18 seconds
• Processing cost: ~$0.14 per part
• Total part cost: ~$0.17 at 10,000 units
• Program total (mold + 10,000 parts): $5,200

Part B: Device Housing

• Material: PC/ABS, 85 grams, single cavity
• Medium complexity, 2 side actions, SPI B-1 finish
• P20 mold: $8,500
• Material cost: $0.43 per part
• Cycle time: 35 seconds
• Processing cost: ~$0.27 per part
• Total part cost: ~$0.70 at 10,000 units
• Program total (mold + 10,000 parts): $15,500
• At 100,000 units, switching to a 4-cavity H13 mold ($28,000, part cost ~$0.28): program total = $56,000 (saves $14,000 vs continuing with single-cavity)

Part C: Automotive Bracket

• Material: PA66-GF30, 180 grams, single cavity
• High complexity, 3 side actions, H13 tooling, PPAP Level 3 documentation
• H13 mold: $22,000
• Material cost: $1.15 per part
• Cycle time: 45 seconds
• Processing cost: ~$0.35 per part
• Total part cost: ~$1.50 at 10,000 units
• Program total (mold + 10,000 parts): $37,000

How to Reduce Injection Molding Cost

Design changes that reduce mold cost:

• Eliminate undercuts — redesign snap-fits to eject in the draw direction. Each undercut eliminated saves $800–$2,500.
• Relax surface finish requirements — specifying VDI 24 texture instead of SPI A-2 polish eliminates 8–16 hours of polishing labour.
• Reduce part size where possible — smaller part → smaller mold base → less steel → lower mold cost.
• Design for single-cavity initially — prove the market before investing in multi-cavity tooling.

Process decisions that reduce part cost:

• Increase cavitation at the right volume — the break-even for adding a second cavity is typically reached when annual volume exceeds the single-cavity annual output by 30–40%.
• Optimize cycle time — a well-designed cooling system reduces cycle time by 15–25% versus a basic cooling layout. The cooling design pays for itself within the first 50,000 shots.
• Material selection — PA6 instead of PA66 where the 20°C lower HDT is acceptable. ABS instead of PC/ABS where impact requirements allow. The material specification is the largest per-part cost lever after cavitation.

Frequently Asked Questions

Why do mold quotes vary so much between suppliers?

Three reasons. First, differences in steel grade and tool life — a $5,000 P20 mold and a $12,000 H13 mold are not the same product. Second, assumptions about cavitation, cooling, and automation that the buyer did not specify — suppliers fill the gap with different assumptions. Third, genuine differences in overhead, labour rates, and margin structure between suppliers. The solution: specify the steel grade, cavity count, and expected shot life in your RFQ. All quotes will then be for the same thing.

What is the single biggest mistake buyers make on cost?

Choosing the cheapest mold, then paying for it in per-part cost for the next five years. A $3,000 saving on the mold is lost within 30,000 parts if the per-part cost is $0.10 higher.

Do you charge for DFM analysis?

No. DFM review is included with every quote. We analyse your part file and return a written report — material recommendation, gate location, draft analysis, undercut identification, and a cost estimate for tooling and per-part pricing. This is provided at no charge and with no obligation.

When does it make sense to invest in a hot runner?

When the annual material savings from eliminating the cold runner exceed the amortized cost of the hot runner system. As a rough guide: for parts under 20 grams with engineering-grade materials, hot runners typically pay back within 12–24 months at volumes above 200,000 parts per year. For larger parts or lower volumes, cold runner is usually the more economical choice.

How do I compare quotes from different suppliers fairly?

Send the same specification to every supplier: steel grade, cavity count, expected annual volume, surface finish requirement, and target shot life. If you only send a 3D file with “please quote,” you will receive quotes for different tools — and the comparison will be meaningless.

Injection molding cost is not a mystery. It is a function of steel, resin, machine time, and volume. The buyers who get the best results are the ones who understand which costs are fixed, which are variable, and where the trade-offs live — so they can make informed decisions rather than chasing the lowest number on a quote.
