See Our Shenzhen Facility

The best way to verify a manufacturing partner is to see their facility. This virtual tour walks you through every department at JBRplas — mold design and tooling, injection molding, quality control, assembly, and logistics. All images shown are our actual facility, equipment, and team in Shenzhen, China.

Jump to: Factory & Workshop · Mold Toolroom · Injection Molding · Quality Lab · Engineering · Assembly

Factory & Workshop

JBRplas operates from a 10,000 m² facility in Shenzhen, Guangdong, with 150+ employees, 25 engineers, and all manufacturing under one roof — mold making, injection molding, and assembly.

The exterior of the JBRplas factory in Shenzhen, Guangdong — ISO 9001 and ISO 13485 certified plastic injection mold manufacturing facility
Factory exterior — Shenzhen, Guangdong
Interior of the JBRplas injection molding workshop with 30+ servo-hydraulic presses ranging from 60T to 500T
Injection molding workshop — 30+ presses, 60T to 500T

Mold Toolroom

Our in-house toolroom is where every injection mold is built, from single-cavity prototypes to high-cavitation production tooling. Equipment includes 12 CNC machining centers, 6 EDM sinkers, 4 wire-cut EDM machines, and 4 surface grinders — all operated by experienced toolmakers averaging 12+ years in the trade.

CNC machining center cutting an injection mold cavity insert — high-speed 3-axis and 5-axis CNC with ±0.005mm precision at JBRplas Shenzhen
CNC machining — mold cavity insert, ±0.005mm precision
YCM high-speed CNC machining center in operation at JBRplas Shenzhen toolroom — precision mold component manufacturing
YCM high-speed CNC — precision mold components
EDM sinker machine burning mold cavity detail — achieving Ra 0.2μm surface finish at JBRplas Shenzhen toolroom
EDM sinker — Ra 0.2μm surface finish
DMAPK EDM machine at JBRplas Shenzhen — high-precision electrical discharge machining for complex mold cavities
DMAPK EDM — complex mold cavity machining
Double-heads EDM machine at JBRplas Shenzhen toolroom — simultaneous dual-electrode machining for faster mold production
Double-heads EDM — dual-electrode, faster cycle times
Overview of the JBRplas toolroom with CNC, EDM, wire-cut, and grinding stations — Shenzhen mold manufacturing facility
Toolroom overview — CNC, EDM, wire-cut, grinding
Mold assembly workstation at JBRplas Shenzhen — skilled toolmakers fitting and assembling precision injection molds
Mold assembly — fitting and finishing precision molds
Mold assembly workshop overview at JBRplas Shenzhen — multiple assembly bays for concurrent mold builds
Mold assembly workshop — multiple concurrent builds

Injection Molding Floor

30+ servo-hydraulic injection presses from 60T to 500T, with automated part removal on 80% of presses. We process 500+ resin grades including engineering thermoplastics (ABS, PC, PA66, POM, PBT-GF30), high-temperature resins (PEEK), and medical-grade materials.

JBRplas injection molding production floor with rows of servo-hydraulic presses — Shenzhen plastic injection molding factory
Injection molding floor — servo-hydraulic presses, automated part removal
Close-up of a servo-hydraulic injection molding press showing the clamping unit and barrel — precision molding at JBRplas
Servo-hydraulic press — precision injection molding
Fuli in-house plastic component manufacturing capabilities — injection molding production at JBRplas Shenzhen
In-house plastic component manufacturing — full production capability
Low-volume production batch of precision injection molded parts at JBRplas — suitable for 500 to 10,000 piece runs
Low-volume production — 500 to 10,000 piece batches
Injection molding workshop line No.1 at JBRplas Shenzhen — servo-hydraulic presses with automated part removal and real-time process monitoring
Workshop line No.1 — automated part removal, SPC monitoring

Quality & Inspection Lab

Our quality lab is equipped with CMM coordinate measuring machines (Zeiss / Hexagon, ±0.002mm), optical comparators, surface roughness testers, hardness testers, and spectrophotometers — all calibrated on schedule with certificates traceable to national standards.

CMM coordinate measuring machine inspecting an injection mold component at JBRplas quality lab — Zeiss / Hexagon, ±0.002mm
CMM inspection — Zeiss / Hexagon, ±0.002mm
QC technician performing dimensional inspection on an injection molded part at JBRplas Shenzhen — ISO 9001 certified quality control
QC workstation — dimensional inspection, ISO 9001 certified
Precision measurement instruments — micrometer, pin gauges, digital height gauge — used for injection molded part inspection at JBRplas Shenzhen
Precision measurement instruments — traceable calibration
First-off dimensional inspection of an injection molded part — full dimensional report against drawing tolerances at JBRplas
First-off inspection — full dimensional report
Real-time SPC statistical process control monitoring on the injection molding floor — critical dimensions tracked every 50–100 shots at JBRplas
SPC process monitoring — real-time, every 50–100 shots

Engineering & Design

Every project at JBRplas starts with our engineering team — not the shop floor. We run a documented DFM review and Moldflow simulation (fill, warp, cooling analysis) before any steel is cut. The team works in SolidWorks, UG NX, and Pro/E, and supports STEP, IGES, and all common CAD formats.

DFM engineering workstation at JBRplas Shenzhen — every project begins with a design for manufacturability review and Moldflow simulation
DFM engineering workstation — design review before tooling begins
Integrated engineering and project management office at JBRplas Shenzhen — engineers co-located with production for seamless communication
Integrated office — engineering co-located with production

Assembly & Finishing

Post-molding services include manual and semi-automated assembly, ultrasonic welding, heat staking, pad printing, screen printing, spray painting, chrome plating, laser engraving, and custom packaging — all in-house. No third-party suppliers. No quality gaps.

Assembly line at JBRplas Shenzhen — manual and semi-automated assembly, ultrasonic welding, pad printing, and custom packaging
Assembly line — manual & semi-automated, all in-house
Screen printing workshop at JBRplas Shenzhen — in-house screen printing for plastic injection molded parts, enclosures, and panels
Screen printing workshop — enclosures and panels
Screen printing production station at JBRplas Shenzhen — multi-colour screen printing capability for branded OEM parts
Screen printing station — multi-colour, OEM branded parts

Ready to Visit in Person?

We welcome customer visits to our Shenzhen facility. Walk the shop floor, meet your dedicated project engineer, and inspect your mold build in progress. Factory audits and supplier qualification visits are standard practice — we make them easy.

  • Address: Shenzhen, Guangdong, China (detailed directions provided when you schedule)
  • Languages: English, Mandarin, Cantonese
  • What to expect: Full facility tour, engineering team introduction, in-progress project review
